The Quick Test functionality of the Brookfield RSO Rheometer allows testing within minutes.
The RSO Stand-alone mode with easy-to-use interface makes it simple for QC Users, it can also help in Viscoelastic measurements by providing R&D users with advanced testing capabilities. RSO Flexibility allows cone/plate and concentric cylinder in a single instrument.
FEATURES AND BENEFITS
-
Controlled shear stress/shear rate operation makes it easy to study static yield to flow curve and visco- elastic behaviour.
-
User-friendly Touch Screen and graphical display for stand-alone operation.
-
Quick Connect Coupling System for easy spindle attachment.
-
Instrument flexibility allows for cone/plate and concentric cylinder in one.
-
Very Small Sample Size permits rapid test set up and clean up.
-
Spindle Barcode for auto spindle recognition.
-
Standalone simplicity for QC users.
-
Automatic Gap Setting for quick and easy gap setting.
-
Rapid Temperature Control of plate with Peltier option for quick profiling of viscosity vs. temperature.
-
Optional Rheo3000 Software allows for PC control and data acquisition/analysis of multiple test files.
OPTIONAL ACCESSORIES
-
Choice of cone or plate spindle geometries (at least one is required)
-
Rheo3000 Software
-
Viscosity Standards
-
Choice of Thermal Barrier
-
Teflon (0° – 200°C)
-
Stainless Steel (0° – 200°C+)
-
Coaxial Cylinder
-
Bob (spindle) and Chamber
-
FTKY3 Water Jacket for Temperature Control
-
Temperature Bath
SPECIFICATIONS
|
Min Torque |
5μNm |
|
Max Torque |
100mNm |
|
Resolution of Torque |
0.02μNm |
|
Bearing |
Air bearing |
|
Resolution of deformation |
1.25μrad |
|
Min speed |
0.001rpm |
|
Max speed |
1500rpm |
|
Min frequency |
0.001 Hz / 0.006 rad/s |
|
Max frequency |
20 Hz / 126 rad/s |
|
Measurement system |
Cylinder/Cone Plate |
|
Temp control |
Peltier or bath option |
|
Min Temp. |
0° C |
|
Max Temp |
180° C |
|
Size W×H×D |
360×600×340mm |
|
Weight |
31kg |
What's Included
-
Instrument with Peltier temperature control for sample plate
-
Convenience Package, which includes cleaning cloth and screen protector
-
Air Filtration System is added to all orders unless specifically removed
