Series 2 digital force gauges are designed for basic tension and compression force testing applications up to 500 lbF (2,500 N). Peak tension and compression readings are reliably captured via the gauges' ±0.5% accuracy and 500 Hz sampling rate. A backlit graphic LCD displays the current, peak tension, or peak compression reading.
The gauges are overload protected to 200% of capacity. An ergonomic, reversible aluminum housing allows for hand held use or fixture mounting, rugged enough for applications in both production and laboratory environments. Series 2 gauges are directly compatible with Mark-10 test stands and grips.
Features :
-
Calculates peak tension and compression values
-
3 selectable units of measurement
-
Ultra-compact, ergonomic housing
-
Configurable default measurement unit and mode
-
500 Hz sampling rate
-
Large, backlit graphic display with auto-dimming
-
Powered by 9V battery or available AC adapter
-
Reversible housing for alternate load cell orientation
Specifications:
|
Accuracy:
|
±0.5% of full scale
|
|
Sampling rate:
|
500 Hz
|
|
Power:
|
AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.
|
|
Battery life:
|
Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use
|
|
Measurement units:
|
lbF, kgF, N
|
|
Safe overload:
|
200% of full scale (display shows “OVER” at 110% and above)
|
|
Weight:
|
M2-2 – M2-100: 0.7 lb [0.33 kg]
M2-200 – M2-500: 0.9 lb [0.41 kg]
|
|
Shipping weight:
|
M2-2 – M2-100: 3 lb [1.4 kg]
M2-200 – M2-500: 3.2 lb [1.5 kg]
|
|
Environmental requirements:
|
40 – 100°F, max. 96% humidity, non-condensing
|
|
Warranty:
|
3 years (see individual statement for further details)
|
|
HS code:
|
Model no.
|
HS code:
|
|
M2 (all capacities)
|
9024100000
|
|
CERT
12-1049
AC1118
AC1030
AC1031
AC1032
AC1035
AC1052
|
9024800000
|
|
ECCN:
|
EAR99
|
|
Country of origin:
|
USA
|
