Description

Easy-to-Use Charge Plate Monitor For Manual or Automated Testing

The Monroe?? 288C is an easy-to-use, charge plate monitor for manual or automated testing. All test parameters are programmable, allowing tests to be optimized and not dictated by equipment limitations. Once programmed, the Monroe?? 288C will perform a series of tests automatically: ± decays, balance, balance peaks, temperature, humidity, time/date are stored and may be reviewed via the display or downloaded to a PC. The included software permits the user to define and name ionizer locations, test setups, and sequences and upload them to the CPM. All of these features result in a flexible, easy-to-use instrument that facilitates audits while minimizing errors.

Features

Internal battery for portable operation
Detachable 6 x 6-inch plate with optional 1 x 1 in and 3 x 3 in plates
Built-in temperature and humidity sensors
Auto-ranging to 0.1 V resolution below 100 V Meets ESD Association Standard ANSI / ESD STM 3.1
CE compliant

Benefits

Perform manual and automated testing of decay and balance
Store up to 1500 tests total (not for each location), 600 locations, and 4 test protocols
Use the large, easy-to-read, high contrast LCD display
Configure operating parameters
Utilize soft keys for highly intuitive programming
