Measure wire crimp pull forces up to 200 lbF [1 kN] accurately and efficiently with the WT-205M motorized pull tester. Portable and customizable, the tester conforms to numerous UL, ISO, ASTM, SAE, MIL, and other requirements for destructive and non-destructive testing. Pull to break, pull to load, or maintain a load for a specified period of time (optional functions), as per the requirements of UL 486A/B. Programmable pass/fail limits with red and green indicators and audio alerts help identify non-conforming samples.
The tester's standard adjustable terminal fixture contains multiple slots for diameters up to AWG 3 (0.25 in [6.3 mm]), while the self-tightening wedge grip securely clamps the free end of the cable. To accommodate a wide range of materials, optional and interchangeable alternative grips are available.
Samples can be sent to Mark-10 for evaluation and recommendation prior to purchase.
The WT-205M stores and calculates statistics for up to 2,000 readings, with available date and time stamps for each saved data point.
Data can be transferred to a PC or other data collector via USB, RS-232, Mitutoyo (Digimatic), or analog outputs. Upon sample break, the tester can auto-reverse, save and output the peak force, and auto-zero in preparation for the next test, increasing testing efficiency.
The available Profiles function allows the user to create and save test setups for quick recall. The WT-205M includes MESUR® Lite data acquisition software. MESUR® Lite tabulates continuous or single point data. One-click export to Excel allows for further data manipulation.
Feature
-
Measures real-time and peak force values
-
Selectable test speed, w/high speed approach and reverse
-
Auto-reverse at sample break or load
-
USB, RS-232, Mitutoyo (Digimatic), and analog outputs
-
Automatic reverse / output / data storage / zeroing upon sample break helps automate testing processes
-
2,000-point data memory with statistics, output, and date and time stamp (date and time stamp is optional)
-
Password protection prevents unauthorized changes
-
Pass / fail indicators, audio alerts, and outputs
-
Save and recall up to 500 profiles for various test requirements (optional function)
-
Pull to a specified load or maintain load for a specified period of time, as per UL 486A/B (optional functions)
-
Date / time stamp for all saved data (optional function)
Specifications
-
Capacity x Resolution: 200 x 0.1 lbF | 3200 x 2 ozF | 100 x 0.05 kgF | 1,000 x 0.5 N | 1 x 0.0005 kN
-
Accuracy: ±0.2% of full scale
-
Wire gauge range*: AWG30 - AWG 3* [0.01 - 0.25 in (0.3 - 6.3 mm) dia.]
-
Sample length range: 2.1 in [53.3 mm], excluding termination
-
Max. elongation: 2.3 in [58.4 mm]
-
Speed range: Test speed: 0.4 - 12.0 in/min [10 - 300 mm/min]
-
Approach/reverse speed: 12.0 - 25.0 in/min [300 - 625 mm/min]
-
Return speed: 12.0 -45.0 in/min [300 - 1,125 mm/min]
-
Speed setting accuracy: ±0.2%
-
Speed variation with load: ±0% [Stepper motor driven]
-
Power: Universal input 80-240 VAC, 50/60 Hz
-
Sampling rate: 7,000 Hz
-
Outputs: USB / RS-232: Configurable up to 115,200 baud.
-
Mitutoyo: Serial BCD suitable for all Mitutoyo SPC-compatible devices.
-
Analog: ±1 VDC at capacity, ±0.25% of full scale.
-
General purpose: Three open drain outputs, one input.
-
Set points: Three open drain lines, 40 VDC max., 100 mA DC max.
-
Overload protection: Motor stops at 120% of full scale of the force sensor (display shows “OVER” at 110% and above)
-
Weight: 28 lb [12.7 kg]
-
Shipping weight: 33 lb [15.0 kg]
-
Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensing
-
Warranty: 3 years (see individual statement for further details)
