BCT-01 Box Compression Tester

Packaging Testing Equipment

BCT-01 Box Compression Tester is professionally used to test the compression resistance property of carton boxes, corrugated boxes, honeycomb cardboard boxes, and other packaging. It is also applicable to container compression testing of plastic buckets (edible oil, mineral water), fiber drums, carton paper, cans, and container barrels (IBC barrels).

Full Description

CHARACTERISTICS

  • Minicomputer control;

  • High-speed ARM processor;

  • High automaticity, fast data collection, test automatically and intelligent judgment;

  • Three test methods: compression test, stacking test, press standard test;

  • Screen dynamic displays sample No., sample deformation, real-time pressure and initial pressure;

  • Servo motor controls with high precision, low noise and high speed advantages;

  • Accurate position and fast response speed save test time;

  • 24 high-precision AD converter (resolution up to 1/10,000,000) and high precision weighing sensor to ensure the speed and accuracy of the data acquisition of the instrument force;

  • Ultimate travel protection, overload protection, bugs prompt and fault prompts intelligent configuration to ensure safe operation;

  • Micro-printer can print test data easily;

  • Connecting with computer can display curve, analyze test data, save and print data.

Specifications

Test Range20 kN, 50 kN (Optional)
Accuracy1% of Reading Value
Force Resolution1 N
Deformation Resolution:0.1 mm
Pressing Plate:Parallelism between upper and lower pressing plate: ≤1 mm
Test Speed:5 mm/min, 10 mm/min
Return Speed:1–60 mm/min
Stroke:700 mm
Specimen Dimension600 mm × 600 mm × 600 mm
Power SupplyAC 220V, 50 Hz

Applicable standards

ISO 2872, ISO 2874
